SA1000 Antenna
Mini GNSS Antenna for Reference Station
MINI CHOKE RING ANTENNA
Stonex SA1000 is a high performance mini Choke Ring GNSS antenna with strong multipath suppression and submillimeter phase center stability. This antenna is ideal for use in installations for monitoring or CORS for the creation of a Network VRS. The advantage of this antenna is to have excellent performance in small dimensions, it has a diameter of only 213mm and a low weight of 3Kg. This allows easy installation compared to the standard Choke Ring antenna which have larger dimensions and weight.
TRACKING OF ALL GNSS SIGNALS
SA1000 is able to track all signals (L1, L2, L3/L5) of all available constellations: GPS, Glonass, Galileo, BeiDou, QZSS, IRNSS, SBAS and the L-band correction service.
The strong ability to receive low elevation signals with high gain and wide beam width makes SA1000 an excellent choice for tracking visible satellites and provide stable and precision GNSS data under complex environments, such as obstructed environment of tree lines or construction.
STRONG AND RUGGED
The SA1000 radome is made of Glass Fiber Reinforced Polymer(GFRP) material and is structurally strong and reliable. The IP67 ruggedized cover is also designed to protect the inside antenna from dust and water. SA1000 is the perfect compromise of a compact antenna, performing but with a very competitive price.
